RRE Mandrel Bent Exhaust Bends and Intercooler Bends

Stainless Steel Mandrel Bends

2 1/2" DSM Down Pipe First Bend $30

Mandrel bent 2 1/2" 409 stainless steel. 72 degree bend is the perfect bend for making your own DP. Has a 12" leg to go under the oil pan and will connect to a flex section. You need to trim to fit to the O2 flange. For a 3" DP use a 90 degree bend to clear the cross member better.

439 Stainless Steel 3.0" Outside diameter .064" wall thick

Outside Diameter
Radius

Part #

Use

Price

3.0" 90 Degree w/ 8" leg
4"
BEND-SS-300-90 Exhaust or Intake
$32

3.0" 45 Degree w/ 8" leg
4"
BEND-SS-300-45 Exhaust or Intake
$32

439 Stainless Steel 2.5" Outside diameter .064" wall thick
Outside Diameter	Radius	Part #	Use	Price
2.50" 90 Degree w/ 7" leg	3"	BEND-SS-250-90	Exhaust or Intake	$26
2.50" 45 Degree w/ 7" leg	3"	BEND-SS-250-45	Exhaust or Intake	$26

Aluminum Intercooler/Intake Bends

These 6061 aluminum bends must be TIG welded (expensive welder that requires a lot of skill). Aluminum is the light weight and is very easy to cut and trim. Also very easy to bead since it is very soft. It can be polished, anodized, painted or left alone.

Aluminum 2.25" Outside Diameter Bend .070" wall thickness
Outside Diameter	Radius	Part #	Use	Price
2.25" U-Bend w/ 8"leg	3"	BEND-ALU-214-U	Intercooler & Intake	$25

Aluminum 2.5" Outside Diameter Bend .070" wall thickness
Outside Diameter	Radius	Part #	Use	Price
2.5" U-Bend w/ 8"leg	3"	BEND-ALU-250-UB	Intercooler & Intake	$28
2.5" 90 Degree w/ 8" leg	3"	BEND-ALU-250-90		$26
2.5" 45 Degree w/8" leg	3"	BEND-ALU-250-45	"	$26
2.5" Straight 3' Length		TUBE-ALU-250-3F		$25

Aluminum 3.0" Outside Diameter Bend .070" wall thickness
Outside Diameter	Radius	Part Number	Use	Price
3.0" U-Bend w 8" leg	4"	BEND-ALU-300-UB	Intercooler piping & intake	$34
3.0" 45 Degree w/ 8" leg	4"	BEND-ALU-300-45	"	$32
3.0" 90 Degree w/8" leg	4"	BEND-ALU-300-90	"	$32
3.0" Straight 3' Length		TUBE-ALU-300-3F		$28

Aluminized Steel Exhaust Bends

These aluminized tubes have a thin electro-coating of aluminum on them that drastically reduces corrosion over time. This thin coating does not affect welding and can be welded with any MIG or TIG welded with regular steel welding rod. The thicker 14 gauge wall makes for the best bang for the buck exhaust piping.

Aluminized Steel Exhaust 2.5" Bends 14 Gauge
Outside Diameter	Radius	Part #	Use	Price
2.5" 45 Degree Bend	4"	BEND-AMZ-250-45		$25
2.5" Straight 3' Length		TUBE-AMZ-250-3F		$20

Plain Steel Intercooler Tubing Bends

These plain steel bends are best used for intercooler piping. They are a thinner wall allowing them to be more easily cut and trimmed and beaded. The plain steel welds nicely with any welder. They will need to be painted or powder coated to prevent rust over time. While you can get them chromed, they will not hold a polish. For straight tubing, see the bottom of this page.

Tips for beading I/C pipes.

2.25" Steel Intercooler Tubing Bends 16 Gauge
Outside Diameter	Radius	Part #	Use	Price
2.25" U Bend (16 Ga)	3"	BEND-STL-214-U	J Pipe (2G)	$17
2.25" 90 Degree Bend	3"	BEND-STL-214-90	Lower 90 Pipe (2G)	$15
2.25" 45 Degree Bend	3"	BEND-STL-214-45	Turbo Inlet Pipe (2G)	$15
2.25" Straight 3' Length		TUBE-STL-214-3F		$16

3" Steel Intercooler Tubing Bends 16 Gauge
Outside Diameter	Radius	Part #	Use	Price
3" U Bend	4"	BEND-STL-300-U	Big Turbo Inlet	$22
3" Straight 3' Length		TUBE-STL-300-3F		$20

Other Bends

Outside Diameter	Radius		Use	Part #	Price
2.5" to 3" Reducer Aluminized		14 Ga	3" DP to O2 Hsg	AMZ-220-300	$12
1 7/8" U Bend Steel	3"	16 Ga	1G Turbo Outlet	BEND-STL-178-U	$15
2" U Bend Steel	3"	16 Ga	Bigger 1G Turbo Outlet	BEND-STL-200-U	$15
2" 90 Degree Bend Steel	3"	16 Ga		BEND-STL-200-90	$12
2 3/8" U Bend Steel	3"	18 Ga	TB Elbow	BEND-STL-238-U	$20
2 3/8" 90 Degree Steel	3"	18 Ga		BEND-STL-238-90	$18
3" U Bend Steel	6"	16 Ga		BEND-STL-300-U6	$25

Donuts ?

Outside Diameter	Material	Part Number	Radius	Price
1 5/8"	Steel	DNT-STL-158	1 5/8"	$42
1 5/8"	Stainless Steel	DNT-SS-158	1 5/8"	$88
2"	Steel	DNT-STL-200	2"	$45
2"	Stainless Steel	DNT-SS-200	2"	$90
2.5"	Steel	DNT-STL-250	2.5"	$60
2.5"	Stainless Steel	DNT-SS-250	2.5"	$110
3"	Steel	DNT-STL-300	3"	$65
3"	Stainless Steel	DNY-SS-300	3"	$145
Some diameters may be special order and may ship separate a day or two after your other part in the order.

Cast Aluminum Tight Radius Elbows

Description	Radius	Part #	Use	Price
2" 90 Degree Elbow	1.5"	ELB-ALU-200	Compressor Outlet	$28
2.25" 90 Degree Elbow	2.0"	ELB-ALU-214	Compressor Outlet	$30
2.5" 90 Degree Elbow	2.0""	ELB-ALU-250	BIG Turbo Outlet, Weld to I/C	$36
3" 90 Degree Elbow	2.5"	ELB-ALU-300		$38

Straight Tubing

Straight Stainless Steel Exhaust Tubing
Outside Diameter	Part #	Length	Price
2.25"	TUBE-SS-214-3F	3 Feet	$35
2.5"	TUBE-SS-250-3F	3 Feet	$40
3.0"	TUBE-SS-300-3F	3 Feet	$45

Straight Aluminum Intercooler/Intake Tubing

Outside Diameter

Part #

Length

Price

2.25"

TUBE-ALU-214-3F

3 Feet

$22

2.5"

TUBE-ALU-250-3F

3 Feet

$25

3.0"
TUBE-ALU-300-3F
3 Feet $28

Straight Mild Steel Intercooler/Intake Tubing

Outside Diameter

Part #

Length

Price

2.0"

TUBE-STL-200-3F

3 Feet

$15

2.25"

TUBE-STL-214-3F

3 Feet

$16

2.5"

TUBE-STL-250-3F

3 Feet

$18

3.0"
TUBE-STL-300-3F
3 Feet $20
